Jinko 285W Solar Panel (JKM285PP-60)
The Jinko 285W Solar Panel (JKM285PP-60) is a high-performance polycrystalline module designed for efficiency and durability. With a power output of up to 285W, this solar panel is ideal for residential and commercial installations requiring robust performance in diverse environmental conditions. Featuring advanced 5-busbar cell technology, the Jinko 285W Solar Panel delivers high power output while maintaining reliability and longevity.
Key Features of Jinko 285W Solar Panel
- 5 Busbar Solar Cell: Enhanced with 5-busbar cell technology to improve efficiency and appearance, making it suitable for rooftop installations.
- High Power Output: The Jinko 285W Solar Panel achieves a peak power output of 285W, ensuring optimal energy generation.
- PID Resistance: Built to withstand potential-induced degradation (PID), ensuring consistent performance over time.
- Low-Light Performance: Engineered with advanced glass and surface texturing to perform well in low-light conditions, maximizing energy capture.
- Weather Resilience: Certified to endure high wind loads (2400 Pascal) and snow loads (5400 Pascal), making it durable in extreme weather.
- Corrosion Resistance: High salt mist and ammonia resistance certified by TÜV NORD, perfect for coastal and agricultural applications.
- Temperature Coefficient: Improved temperature coefficient reduces power loss at higher temperatures, ensuring stable performance.
Specifications
- Cell Type: Polycrystalline, 157 x 157 mm (6 inches)
- Number of Cells: 60 (6x10)
- Dimensions: 1650 x 992 x 35 mm (65.0 x 39.05 x 1.37 inches)
- Weight: 19.0 kg (41.9 lbs)
- Front Glass: 3.2 mm, anti-reflection coating, high transmission, low-iron, tempered glass
- Frame: Anodized aluminum alloy
- Junction Box: IP67 rated for water and dust protection
- Output Cables: TÜV 1x4.0 mm², customizable length
Electrical Performance
- Maximum Power (Pmax): 285W (STC), 212W (NOCT)
- Maximum Power Voltage (Vmp): 32.2V (STC), 30.2V (NOCT)
- Maximum Power Current (Imp): 8.85A (STC), 7.03A (NOCT)
- Open-Circuit Voltage (Voc): 38.9V (STC), 36.6V (NOCT)
- Short-Circuit Current (Isc): 9.14A (STC), 7.28A (NOCT)
- Module Efficiency (STC): 17.41%
- Operating Temperature: -40°C to +85°C
- Maximum System Voltage: 1000V/1500V DC (IEC)
- Series Fuse Rating: 20A
- Power Tolerance: 0~+3%
Temperature Coefficients
- Pmax: -0.38%/°C
- Voc: -0.31%/°C
- Isc: +0.06%/°C
Warranty and Certifications
- Product Warranty: 12 years
- Linear Power Warranty: 25 years
- Certifications: ISO9001:2015, ISO14001:2015, OHSAS18001, IEC61215, IEC61730, UL1703
Applications
The Jinko 285W Solar Panel (JKM285PP-60) is versatile and suitable for various applications, including residential rooftops, commercial buildings, and off-grid installations. Its durable construction and high efficiency make it a reliable solution for long-term energy needs, ensuring dependable performance and maximizing power output.
The Jinko 285W Solar Panel combines reliability, efficiency, and weather resilience, making it an ideal choice for those looking to invest in sustainable energy solutions. With its high power output and robust design, the Jinko 285W Solar Panel is engineered to deliver optimal performance in diverse conditions.
Jinko Solar Technology Co., Ltd. presents the JKM285PP-60, a high-performance solar panel with a power output of 265-285 Watts. This poly-crystalline module features a positive power tolerance of +37%. It has been certified to ISO9001:2015 and OHSAS18001 standards. Key features include a 5-busbar solar cell design for improved efficiency, high power output, PID resistance, low-light performance, severe weather resilience, and durability against extreme environmental conditions.
The Jinko 285W Solar Panel (JKM285PP-60) product features engineering drawings, electrical performance, and temperature dependence curves. The module type is poly-crystalline, with dimensions of 1650*992*35mm. The weight is 19kg, with a front glass thickness of 4mm and an antireflection coating. The packaging configuration is a frame-anodized aluminum alloy, with two pallets per stack. The output cables are TUV certified.
