Overview
SolarEpic EPIPDB-COM is a dual battery PWM charge controller designed for solar panels only. It supports 12/24V auto-work and can charge two separate battery banks for RVs, caravans, and boats. This controller has no load terminals.
Key Features
- Dual battery charging to avoid using two separate solar charging systems
- Intelligent System Optimum Control
- 12/24V auto work
- Battery type selection
- Charging frequency optional
- High efficient Series PWM charging
- Local external temperature compensation
- Remote temperature sensor optional
- MOSFET electronic switching (no mechanical switch)
- Remote meter MT-1 optional
- Electronic protection: over charging, short circuit, battery reverse polarity protection
- Microcontroller digital accuracy
Specifications
| Model | EPIPDB-COM |
| Current rating options | 10A / 20A |
| System voltage | 12/24V auto-work |
| Controller type | Series PWM |
| Battery banks supported | Dual battery (two battery banks) |
| Load terminals | No load terminals |
| Notes | For use with solar panels only |
Applications
- RVs
- Caravans
- Boats
For compatibility questions (including the optional MT-1 remote meter or remote temperature sensor), contact support at https://tsolar.top/ or service@tsolar.top.
